GPI 162020-03 Model: G20-012AD+FK 12V DC Modular Fuel Transfer Pump
20 GPM, 1 in. NPT Inlet/Outlet, Automatic Nozzle and Filter
Ships From Manufacturer
Select Model & Quantity:
| Model # | Description | Price | Qty |
|---|---|---|---|
| 162020-03 | 20 GPM, 1 in. NPT Inlet/Outlet, Automatic Nozzle and Filter | $829.99 |
GPI - 162020-03 - Model: G20-012AD+FK 12V DC Modular Fuel Transfer Pump
The GPI G20 Series Fuel transfer pump is the first gear pump to deliver TRUE 20 GPM with a 14 ft. hose and automatic nozzle. Delivering flow rates up to 20 GPM (76 L/min) in three available pump models, the G20 is the first pump in GPI's G series. Its new innovative design features simplified connection points that make attaching accessories fast and easy, and its unique rotary gear design ensures long product life with minimal maintenance. The G20 is durable, manufactured from high-quality diecast aluminum, easy to use, and engineered to last, featuring a self-priming rotary gear design.
G20 Data Sheet- Quick-fit modular makes it easy to attach a meter to build your own custom system
- Diecast aluminum housing is lightweight - weighs 19lbs = low stress on tank
- Powder coated body to prevent rust and survive all weather conditions
- Drip catch - Lockable nozzle holder keeps your truck and tanks clean and stops fuel theft
- Rotary gear design: fewer moving parts means less friction and wear on components, for minimal maintenance and a longer pump life
- Factory-Installed power cord saves installation time
- Spin collar mount makes installation and pump orientation easy - fits any 2" NPT tank
Specifications:
- Max. Flow Rate: 20 GPM (76 L/min)
- Voltage Input: 12V (DC)
- Technology: Rotary Gear
- Amps Rated: 34 amps
- Duty Cycle: 30 min on/30 min off
- Power Cord: 18 ft. (5.5m), 12/2 AWG, Factory Installed
- Max. Discharge Pressure: 12 PSI (0.82 bar)
- Operating Temperature: -22° F to 131° F (-30° C to 55° C)
- Suction Lift: Up to 10 ft. (3 m) at Sea Level 70° F (21.1° C)
- Discharge Lift: Up to 15 ft. (4.5m) at Sea Level 70° F (21.1° C)
- Pump Housing Material: Powder Coated, Corrosion-Resistant Diecast Aluminum
- Wetted Materials: Acetal | Aluminum | FKM | NBR | PPS | Stainless Steel
- Mounting Type/Thread: Spin Collar, 2in. MNPT
- Suction Pipe: Polypropylene, Telescoping 15 to 40in. x 1in. MNPT
- Inlet: 1 in. FNPT
- Outlet: Modular, 1 in. FNPT
- Dispensing Hose: 14 ft. (5.2m) x 1 in. MNPT
- Nozzle: 1 in. FNPT Inlet, Automatic Shut-off, Diesel
- Nozzle Holder Type: Lockable
- Warranty: Limited Lifetime Warranty
- Approvals: cULus Motor Listed for Hazardous Locations Class I, Division 2, Group D USA and Canada
