Hannay Reels 45-02 (N515-14-16-8L) Spring Rewind Hose Reel for Air, Water, Hydraulics, Chassis Grease
1/4 in. NPT Inlet(F)/Outlet(F), without Hose, 25 ft. Hose Capacity, 10000 psi, 1/4 in. Hose I.D.
Ships From Manufacturer
Select Model & Quantity:
| Model # | Description | Price | Qty |
|---|---|---|---|
| 45-02 (N515-14-16-8L) | 1/4 in. NPT Inlet(F)/Outlet(F), without Hose, 25 ft. Hose Capacity, 10000 psi, 1/4 in. Hose I.D. | $404.95 |
Add Optional Accessories
| Model # | Description | Price | Qty |
|---|---|---|---|
| 99 22.0200 | HS-35 Stop with Hardware, (Please Specify Hose OD) | $19.11 | |
| N500-CTNLP | Constant Tension (No Locking Pawl) | $27.30 |
Hannay Reels - 45-02 (N515-14-16-8L) - Spring Rewind Hose Reel for Air, Water, Hydraulics, Chassis Grease
- Compact frame and narrow base.
- Non-sparking ratchet assembly.
- De-clutching arbor to prevent damage from reverse winding.
- Standard inlet: 90° swivel joint, 1/4 in. female NPT threads; 3/8 in. female NPT threads are optional and must be specified.
- Standard outlet: 1/4 in. female NPT threads; 3/8 in. female NPT threads are optional and must be specified.
- Other threads can be furnished and must be specified.
- Standard pressure of 10,000 psi (689 bar), product temperatures from -40° F to +250° F (-40° C to +121° C); optional 1/4 in. 3000 psi (207 bar), or 3/8 in. 3000 psi (207 bar) or 8000 psi (552 bar) are available upon request.
- 4-way roller assembly.
- Constant tension is available consult factory.
- Spring rewind.
