Hannay Reels V-HD5111-62-64-20 Hydraulic Rewind Single Wrap Hose Reel for Jet Fuel, Avgas
1-1/2 in. Inlet/Outlet, 100ft. capacity, 600 psi., 1-1/2 in. I.D.
Ships From Manufacturer
Select Model & Quantity:
| Model # | Description | Price | Qty |
|---|---|---|---|
| V-HD5111-62-64-20 | 1-1/2 in. Inlet/Outlet, 100ft. capacity, 600 psi., 1-1/2 in. I.D. | $3,949.40 |
Add Optional Accessories
| Model # | Description | Price | Qty |
|---|---|---|---|
| V-5000-AUXRWND | Auxiliary Crank Rewind on Powered Reel | $159.25 | |
| V-5000-FWFRAME | Full Width Frame | $227.50 | |
| V-5000-AIRBRAKE | Air Brake added to included Reduction Unit | $200.20 |
Hannay Reels - V-HD5111-62-64-20 - Hydraulic Rewind Single Wrap Hose Reel for Jet Fuel, Avgas
- Effortless and fast rewinding, wrapping, and guiding of hose.
- Chain and sprocket drive powered by electric, hydraulic, or compressed air motor.
- Auxiliary crank rewind, optional.
- 12v rewind, comet brake, reduction unit standard.
- Air brake optional.
- Inlet and hub assembly are aluminum and/or stainless steel for jet fuel.
- SERIES 5100 (1-1/2"): Standard inlet: 90° ball bearing swivel joint, 1-1/2" female NPT threads, 2" Victaulic groove, flanged riser with 1-1/2" female NPT threads; standard pressures to 600 psi (41 bar); standard fluid temperatures from -25° F to +250° F (-32° C to +121° C).
- SERIES 5200 (2"): Standard inlet: 90° ball bearing swivel joint, 2" Victaulic groove, flanged riser with 2" female NPT threads; standard pressures to 150 psi (10 bar); standard fluid temperatures from -50° F to +180° F (-45° C to +82° C).
- SERIES 5300 (3"): Standard inlet: I-hub (aluminum only) straight 3" Victaulic groove inlet, flanged riser with 3" female NPT threads; standard pressures to 150 psi (10 bar); standard fluid temperatures from -50° F to +180° F (-45° C to +82° C). Optional I-hub joints are available in: 3" 90° flanged or 3" 90° Victaulic.
- Consult factory for other pressures and temperatures.
